With CNC machining, computer programs precisely control every movement of the machine, ensuring unparalleled accuracy and consistency.
CNC machines are capable of running continuously for extended periods without any breaks or interruptions. This allows manufacturers to achieve higher production rates and meet tight deadlines efficiently.
One significant advantage of CNC machining is its ability to handle complex designs with ease, CNC machines can precisely execute complex designs by following instructions from CAD (Computer-Aided Design) programs.
the precise and consistent nature of CNC machining eliminates the need for extensive quality control inspections, saving both time and money in the production process.
| Project | Specification details | |
|---|---|---|
| Processing references | Max machining diameter | Ø20 mm |
| Max machining length | 190mm | |
| Axial maximum drilling diameter | Φ10mm | |
| Maximum axial tapping size | M8 | |
| Maximum spindle speed | 10000rpm | |
| Radial maximum drilling diameter | Φ7mm | |
| Maximum radial tapping size | M6 | |
| Maximum speed of radial power head | ER11:10000/ER16:8000 | |
| Rated speed of radial power head | ER11:8000/ER16:6000 | |
| Maximum extraction length of workpiece | 100mm | |
| Tool size | Number of knifes installation | 6 |
| Tool (turning tool) | 12x12 | |
| Sleeve | Φ25.0 X 4 | |
| Collet guide sleeve | Spindle spring collet | TSUGAMI B0265CCR |
| Power head collet | ER11,ER16 | |
| Guide sleeve | TSUGAMI BS-20#-B | |
| Feed rate | Z1/Z2/X2/Y-axis feed speed | 30m/min |
| X1 | 24m/min | |
| electrical machinery | Spindle drive power | 2.5/3.7KW |
| Power head drive power | 1KW | |
| For cutting fluid | 0.4KW | |
| For spindle cooling | 0.075KW | |
| For lubricating oil | 0.01KW | |
