| Specification | Unit | VMC850 | VMC855 |
|---|---|---|---|
| Table size | mm | 1000*500 | 1000×550 |
| T-solt(NO.×width) | mm | 5*18 | 5×18 |
| Max. table load | kg | 500 | 500 |
| Guide rail type | X/Y/Z linear Guideway | X/Y/Z Linear Guideway | |
| X/Y/Z axis travel | mm | 800*500*500 | 800*550*550 |
| Distance from spindle nose to worktable | mm | 120-620 | 120-670 |
| Distance from spindle center to column | mm | 570 | 580 |
| Spindle taper | BT40 | BT40 | |
| Spindle speed | rpm | 8000 | 8000 |
| Spindle motor | kw | 7.5 | 7.5 |
| X/Y/Z axis motor | nm | 15/15/22 | 15/15/22 |
| X/Y/Z axis rapid feed speed | m/min | 48/48/48 | 48/48/48 |
| Magazine type | Disc | Disc | |
| Magazine Hole Taper | BT40-24 | BT40-24 | |
| Positioning accuracy | mm | ±0.005 | ±0.005 |
| Repositioning accuracy | mm | ±0.004 | ±0.004 |
| Overall size(L×W×H) | mm | 2600x2300x2400 | 2650×2300×2550 |
| Machine weight | T | 4.8 | 5.2T |
We want to know:
1. We strongly suggest you to tell us size, material of your workpiece for our evaluation if possible, better to send us workpiece drawing, so that we can recommend you most suitable model!
2. If need CIF Price, please kindly tell us the port of destination.
