| project | unit | HMC-500 | HMC-630 | HMC-800 | HMC-1000 |
| Table size | mm | 500*500 | 630*630 | 800*800 | 1000*1000 |
| Number of workstations | Standard single workbench, washable and interchangeable double workbench | ||||
| Table rotation | ° | 1°*360 | 1°*360 | 1°*360 | 1°*360 |
| Maximum load | kg | 600 | 1000 | 1500 | 2000 |
| X/Y/Z axis travel | mm | 900/730650 | 1000/350/750 | 1100/1000/950 | 1190/1020/1050 |
| Distance from the center of the spindle to the work surface | 110-860 | 110-960 | 20-1120 | 152-1172 | |
| Distance from the end face of the spindle to the center of the workbench | mm | 60-710 | 60-810 | 50-1000 | 50-1100 |
| Taper specifications (model/installation size) | mm | BT50/Φ190 | BT50/Φ190 | BT50/Φ190 | BT50/Φ190 |
| Maximum spindle speed | rpm | 6000 | 6000 | 6000 | 6000 |
| Three-axis cutting feed rate | mn/min | 10-15000 | 10-15000 | 10-15000 | 10-15000 |
| Three-axis fast movement X/Y/Z | m/min | 30 | 30 | 30 | 30 |
| Positioning accuracy | mm | ±0.015/300 | ±0.015/300 | ±0.015/300 | ±0.015/300 |
| Repeat positioning accuracy | mm | ±0.01/300 | ±0.01/300 | ±0.01/300 | ±0.01/300 |
| Spindle drive motor | kw | 15 | 15 | 18.5 | 22 |
| X/Y/Z drive motor | kw | 3/3/3 | 3/3/3 | 2003/3/4 | 2004/3/4 |
| Tool magazine capacity (optional) | put | 24/32 | 24/32 | 24/32 | 24/32 |
| Floor area (length*width*height) | mm | 4280/3000/2600 | 5900/3500/3563 | 5900/4600/3000 | 7875/4600/3405 |
| Weight of the whole machine (approximately) | T | 8 | 10 | 12 | 15 |
| Remarks | “T” type structure | “T” type structure | “T” type structure | “T” type structure | |
