| Specification | Unit | VMC 1370 | VMC 1580 |
|---|---|---|---|
| Table size | mm | 1400x700 | 1600*800 |
| T-slot (NO.×width×pitch) | mm | 5×18 | 7*18 |
| Max. table load | kg | 1000kg | 1000kg |
| Guide rail type | - | Linear Guideway | X/Y Linear Guideway, Z Boxway |
| X/Y/Z axis travel | mm | 1300×700×700mm | 1500*800*700 |
| Distance from spindle nose to worktable | mm | 100-780 | 190-830 |
| Distance from spindle center to column | mm | 760 | 800 |
| Spindle taper | - | BT50 | BT50 |
| Spindle speed | rpm | 8000 | 6000 |
| Spindle motor | kw | 15 | 15 |
| X/Y/Z axis motor | nm | 23/23/27 | 23/23/27 |
| X/Y/Z axis rapid feed speed | m/min | 24/24/18 | 20/20/12 |
| Magazine type | - | Disc | Disc |
| Magazine Hole Taper | - | BT40-24 | BT40-24 |
| Positioning accuracy | mm | ±0.005 | ±0.005 |
| Repositioning accuracy | mm | ±0.004 | ±0.004 |
| Overall size (L×W×H) | mm | 3800x2600x2950 | 5250*2950*3150 |
| Machine weight | T | 9T | 12T |
