| X/Y/Z-axis travel | 500/400/330mm |
| Distance from spindle end face to table center | 150-480mm |
| X/Y/Z-axis feed rate | 60m/min |
| Cutting feed rate | 1-30000mm/min |
| Spindle taper | BT30 |
| Max.spindle speed | 24000r/min |
| Spindle power | 8.2kw |
| Spindle torque | 26Nm |
| Worktable size | 650x400mm |
| Max.load weight | 300kg |
| Tool capacity | 21pcs |
| Max.tool diameter | 80mm |
| Max.tool length | 250mm |
| Max.tool weight | 3kg |
| Tool change time(Tool-to-tool) | 1.2-1.4s |
| Air supply requirement | ≥6kg/cm² |
| Air source flow | ≥0.5mm³/min |
| Net weight | 2.9t |
| Machine Dimensions(L×W×H) | 1589×2322×2304mm |
Leveraging 10+ years in China's equipment ecosystem, we aggregate 200+ validated models across CNC machining, grinding & milling systems – all customizable to your part specifications.
Every machine we supply is field-proven by Tier-1 manufacturers, delivering ISO-certified precision (±0.002mm repeatability) with 98% uptime reliability.
Share your part drawings → We engineer turnkey equipment solutions (including automation integration) with technical validation reports.
Strategic location in Guangdong's manufacturing hub enables 15-30% cost savings versus imports, while maintaining JIS/Taiwan-grade quality control.
Option A: Machine sign-off upon achieving your KPIs (e.g., ±0.005mm tolerance, 500pcs/hr output). Option B: Full acceptance after 30-day mass production trial with your actual parts.
1-Year Comprehensive Warranty, Remote Diagnostics & Priority Spares, On-site Maintenance Contracts.
