| Specifications | Units | X5032B |
|---|---|---|
| Table size | mm | 1600x320 |
| Table load | kg | 500 |
| T slot (number-width-pitch) | mm | 3-18-70 |
| Table travel (X / Y / Z) | mm | 900/880 (X) 255/240 (Y) 370/350 (Z) |
| Range of table feed | mm/min | XY: 23.5-1180 Z: 8-394 |
| Rapid speed of table | mm/min | XY: 2300 Z: 770 |
| Spindle taper | - | ISO50 7:24 |
| Spindle speed range | rpm | 30-1500 (18 steps) |
| Swivel angle of vertical milling head | ° | ±45 |
| Distance between spindle nose and table surface | mm | 45-415 |
| Spindle motor power | kw | 7.5 |
| Feed motor power | kw | 1.5 |
| Weight | kg | 3000/3300 |
| Overall dimension | mm | 2600×1770×2000 |
1. Versatile Operation: The vertical lifting platform milling machine is a highly efficient general metal cutting machine tool suitable for diverse manufacturing needs.
2. Extensive Processing Capabilities: The spindle taper hole can install cylindrical milling cutters, disk cutters, molding cutters, and end milling cutters directly or via attachments. It is ideal for processing planes, inclined planes, grooves, holes, and gears. Perfect for mechanical manufacturing, molds, equipment, instruments, automobiles, and motorcycles.
Our standard warranty period is one year, during which we will maintain the product free of charge. If any parts or accessories are damaged under proper operation, we will replace them immediately via airmail or express. Note that the GSK, Servo driven parts, motor, and transformer come with a 3-year warranty.
We pack using robust plywood cases to ensure durability and fully protect the goods during shipment. This method offers excellent strength, a large load capacity, and protection against sun, rain, and moths.
Our standard delivery date is one month (30 days) from order confirmation.
Yes, our machines can be customized. If our standard specifications do not fit your production needs, you can provide us with the model requirements and drawings, and we will design and manufacture the machine to meet your demands.
It is highly suitable for processing a wide variety of small components, including milling planes, inclined planes, grooves, holes, and gears across various industrial sectors.
The machine uses a rectangular guide rail structure for superior rigidity, and the work table along with the guide rails undergo ultra audio spark quenching for enhanced durability and wear resistance.
