| Distance between centers | 650mm |
| Swing over bed | 280mm |
| Width of bed | 160mm |
| Spindle bore taper | MT4 |
| Spindle bore | 26mm |
| Spindle nose | D1-4 |
| Range of spindle speed | 70-2000 rpm(12) |
| Range of longitudinal feeds | 0.036-0.364m/r(15) |
| Range of cross feeds | 0.019-0.188m/r(15) |
| Range of inch threads | 6-96tpi9(13) |
| Range of metric threads | 0.25-5.0mm(18) |
| Top slide travel | 80mm |
| Cross slide travel | 150mm |
| Tailstock quill travel | 80mm |
| Tailstock quill taper | MT3 |
| Motor power | 0.75kw |
| Net weight | 250kg |
| Packing size | 1350x750x700mm |
