| Specification | CK0640. |
|---|---|
| Max. swing dia. over bed | 360mm |
| Max. swing dia. over cross slide | 130mm |
| Max. processing length | collet 200mm/chuck 120mm |
| Dia. of spindle | 48mm |
| Spindle taper | MT5 |
| Through hole dia. of drawing pipe | 31mm |
| Spindle speed | 50-2500mm |
| Tool holder | Gang-type tool holder |
| Tool bar section | 20X20mm |
| Main motor power | 3kw |
| X/Z axis torque | 4N.M/4N.M |
| X/Z axis travel/ stoke | 200/240 |
| X/Z axis fast feeding speed | 6/8 m/min |
| Tailstock sleeve travel | 100mm |
| Tailstock taper | MT3 |
| Dimension | 1550*920*1450mm |
| Weight | 850kg |
