| Item | Value |
|---|---|
| table travel (x) (mm) | 780 |
| table travel (y) (mm) | 400 |
| table travel (z) (mm) | 400 |
| machining capacity | Medium Duty |
| spindle taper | R8 |
| range of spindle speed(r.p.m) | 66r.p.m - 4540r.p.m |
| type | VERTICAL |
| voltage | 380V 50Hz |
| weight (kg) | 1500 |
| warranty | 1 Year |
| max. table load(kg) | 200 |
| place of origin | China |
| model number | 4H |
| dimension(l*w*h) | 1600*1700*2250mm |
| key selling points | Competitive Price |
| machinery test report | Provided |
| video outgoing-inspection | Provided |
| Table size | 1270*254MM |
| T-slots(N/W/D) | 3/16/65 |
| Table longitudinal travel | 750(850 manually)mm |
| Table cross travel | 400mm |
| Quill travel | 127mm |
| Distance between spindle nose and table | 0-460mm |
| Arm travel | 400mm |
| Milling head tilting | 90°(left & right); 45° (front & back) |
| Weight | 1200kg |
| Power (kW) | 2.2 |
