| Description | Parameter details | ||
| XYZ working area | 1300*2500*200mm | 1500*3000*200mm | 2000*3000*200mm |
| Table size | 1440X3040mm | 1640*3540mm | 2140*3540mm |
| X,Y,Z Traveling Positioning Accuracy | ±0.03/300mm | ||
| X,Y,Z Repositioning Positioning Accuracy | ±0.03mm | ||
| Lathe Structure | Welded Structure | ||
| X, Y Structure | Gear Wheel Transmission, Shaft Linear Bearings | ||
| Z Structure | Ball Screw, Shaft Linear Bearings | ||
| Max. Consume Power | 20KW | ||
| Max. Speed | 0-60000mm/min | ||
| Max. Working Speed | 0-25000mm/min | ||
| Spindle Power Motor | 9KW ATC spindle | ||
| Spindle Speed | 0-24000RPM | ||
| Working Mode | Servo system | ||
| Working Voltage | AC380V/50/60Hz , 3PH | ||
| Command | G Code, *uoo, *mmg, *plt | ||
| Operating System | SYNTEC or Weihong System | ||
| Interface | Internet line | ||
| Flash Memory | 512M | ||
| Collet | ER32 | ||
| X,Y Working Delicacy | <0.01mm | ||
| Software | Type3 software, Wentai software, Artcam software | ||
| Running circumstance | Temperature: 0°C~45°C, Relative humidity: 30%~75% | ||
| Packing Size | 4000x2150x2200 mm | ||
| Net Weight | 2000KG | ||
| Gross Weight | 2300KG | ||
